Powerology 200W Monocrystalline Portable Solar Panel

Powerology 200W Monocrystalline Portable Solar Panel Overview

The Powerology 200W Monocrystalline Portable Solar Panel is designed to provide a practical source of solar energy for portable power applications. With a peak power rating of 200W, monocrystalline solar cells and efficiency of up to 23.5%, it converts available sunlight into electrical power for compatible power stations and devices.

The panel features an 18V MC4 output and includes an MC4 to XT60 accessory cable measuring 0.5m. Its foldable construction helps reduce the space required for transportation and storage, making it suitable for users who need a portable solar charging solution.

200W Solar Power Output

The Powerology solar panel has a peak power rating of 200W. Its voltage at maximum power (Vmp) is 18V, while the current at maximum power (Imp) is 11.11A. The panel has an open-circuit voltage of 21.6V and a short-circuit current of 13.3A.

Actual solar output depends on sunlight intensity, panel positioning, weather conditions, temperature and the connected charging equipment. The 200W figure represents the panel’s specified peak power under suitable testing conditions rather than a guaranteed continuous output.

Buy Our Camping Accessories in UAE

Key Features

Feature	Description
200W Peak Power	Provides a maximum rated solar power output of 200W under suitable conditions.
Monocrystalline Solar Cells	Uses monocrystalline solar cell technology for portable solar power generation.
Up to 23.5% Efficiency	Solar cells provide efficiency of up to 23.5% according to the supplied specifications.
18V MC4 Output	Provides an 18V MC4 output for connection to compatible solar charging equipment.
USB-A QC 3.0	The junction box includes USB-A output supporting QC 3.0 up to 18W.
18W USB-C Output	Provides USB-C output up to 18W through the integrated junction box.
ETFE Lamination	Uses ETFE lamination on the monocrystalline solar cells.
Foldable Design	Folds into a more space-efficient format for transportation and storage.
IP67 Splash Proof	Features an IP67-rated splash-proof construction.
Wide Operating Temperature	Designed to operate across a temperature range of -10°C to 65°C.
MC4 to XT60 Cable	Includes a 0.5m MC4 to XT60 accessory cable for compatible connections.
Portable Solar Charging	Provides a foldable solar charging option for compatible portable power systems and devices.

Monocrystalline Solar Cell Technology

The panel uses monocrystalline solar cells with cell efficiency of up to 23.5%. Monocrystalline technology provides a compact approach to solar power generation, allowing the panel to deliver its specified 200W peak output within a portable form factor.

The solar cells are laminated with ETFE, which forms part of the panel’s protective construction. The combination is designed for portable solar applications where the panel may be transported, unfolded and used in different outdoor environments.

Electrical Specifications

The Powerology 200W panel has a voltage at maximum power of 18V and a current at maximum power of 11.11A. Its open-circuit voltage is 21.6V, while the short-circuit current is 13.3A.

These electrical characteristics are important when pairing the panel with a portable power station or other solar charging equipment. The connected device should support the panel’s voltage and current characteristics before use.

MC4 and XT60 Connectivity

The main solar output uses an 18V MC4 connection. An included 0.5m MC4 to XT60 accessory cable provides an additional connection option for compatible equipment featuring an XT60 solar input.

Using the correct connection and ensuring that the receiving device is compatible with the panel’s electrical specifications is important for safe and reliable solar charging.

Buy From Our Chargers & Adapters accessories

USB Charging Outputs

The integrated junction box adds direct USB charging functionality to the solar panel. It includes a USB-A output supporting Qualcomm Quick Charge 3.0 up to 18W and a USB-C output rated up to 18W.

These outputs provide convenient charging options for compatible USB-powered devices. Actual charging speed depends on the connected device, its supported charging protocol and the available solar power at the time.

Foldable and Space-Saving Design

The foldable construction is designed to reduce the space required when the panel is being transported or stored. This makes it more practical for portable applications where equipment needs to be packed away between uses.

The panel can be unfolded when solar generation is required and folded again for storage after use. Its portable format is suited to applications involving compatible power stations and other solar-powered equipment.

IP67 Splash-Proof Construction

The panel is specified with IP67 splash-proof protection. This provides an added level of environmental resistance for outdoor use, although the product should still be used according to its intended operating conditions.

Connections should be kept properly secured and protected from conditions beyond the panel’s stated specifications. The IP67 rating should not be interpreted as permission for unrestricted exposure to water in every situation.

Operating Temperature

The specified operating temperature range is -10°C to 65°C. This provides a broad range for portable solar applications in different outdoor environments.

Solar output can vary with environmental conditions, and high or low temperatures can affect the performance of photovoltaic equipment. For best results, the panel should be operated within its specified temperature range.

Buy Mobile accessories from AS2

Portable Solar Charging Applications

The Powerology 200W Monocrystalline Portable Solar Panel can be used as a solar input source for compatible portable power stations and charging systems. Its 200W peak rating provides a useful level of solar generation for portable energy applications.

The integrated USB-A and USB-C outputs also provide direct charging options for compatible devices, while the MC4 and included XT60 connection support allow the panel to work with compatible solar input systems.

The Powerology 200W Monocrystalline Portable Solar Panel combines 200W peak solar power, up to 23.5% cell efficiency, an 18V MC4 output and convenient USB-A and USB-C charging. Its ETFE-laminated monocrystalline cells, foldable design, IP67 splash-proof construction, wide operating temperature range and included MC4 to XT60 cable make it a practical option for compatible portable solar charging applications.

FAQ

1. What is the maximum power output of the Powerology 200W Solar Panel?

The Powerology portable solar panel has a peak power rating of 200W under suitable solar conditions.

2. What type of solar cells does the Powerology 200W panel use?

It uses monocrystalline solar cells with efficiency of up to 23.5% and ETFE lamination.

3. Does the Powerology solar panel have USB charging outputs?

Yes. Its junction box includes USB-A with QC 3.0 up to 18W and USB-C output up to 18W.

4. What type of connection does the Powerology 200W Solar Panel use?

The panel provides an 18V MC4 output and includes a 0.5m MC4 to XT60 accessory cable for compatible equipment.

5. Is the Powerology 200W Portable Solar Panel suitable for outdoor use?

Yes. It features an IP67 splash-proof construction and is specified for an operating temperature range of -10°C to 65°C.
